position: >> apl limit switch >> mechanical switch (2spdt) apl-210nthe valve spacing switch-box is in the automatic control system examines the valve condition one kind of scene measuring appliance, with by valve's opening or the off-position by the switch quantity's signal output, looks by the program control receive or the computer the sampling, after the confirmation, the execution next step the procedure. this product may also take in the autonomous system the important valve chain-like protection and long-distance warning instruction.
characteristic: the
three dimensional position indicator can the clear demonstration valve locate position. the
compression casting aluminum alloy shell, the powder coating, the packaged design outlook is artistic, reduces the valve packing volume, the dependable quality.
double thread connection pair of 1/2 npt pipe fatigue.
signal feedback. (original installation import ohm dragon switch) the
switch position may recognize clearly by the display. the
multi-contacts inscribe the line board internal 8 wiring port to co
the standard protects ip67, may choose ip68
s5gl (omron)
2spdt switch (option: spst-nc, spst-no)
electronic contact: 250v ac/3a,125v ac/5a
250vdc/0.2a,125vdc/0.4a,30vdc/4a;
s10gl (omron)
electronic contact: 250v ac/10.1a,125v ac/10.1a
250vdc/0.2a,125vdc/0.4a,30vdc/4a
through authentication: ul, csa, semko, sev en61058-1
