position: >> eight improvement >> product technology to improveaox series actuators improved eight
aoxian dedicated to the research, development, design, manufacture actuators for 40 duonian history, therefore, aoxian in this experience and technology is incomparable. to come to china we also insists on the precise and reliable principle, choice and we concept and being creditworthy ryan long macro cooperation, the production aox series of electric actuators, service in industrial fluid control field.
of course, create more and better industrial process control product is endless challenge.
aoxian the courage to accept the challenge! we can do it. ok!!!!! aox!!!!!
a, protection grade of ip68
1. through the improvement of product and joint surface cover concave-convex structure (figure 1)
2. lens structure (figure 2)
avoid using chemical adhesive for working conditions on site (such as high temperature and high pressure) and causes aging water.
after the improvement products fully meet the outdoor working condition, or even a short time soaking in electricity use. (such as output shaft seal don't wear a long time diving use)
second, more reasonable and reliable transmission part
1. gear box all adopt the aluminum alloy material, stop the gear box craze.
2. gear all adopt the 40 chrome through second finish machining and heat treatment, the more solid and reliable into.
。
three, the motor temperature rise more low
through the increase in the same size, motor power, reduced the capacitance capacity, reducing the starting current, reduce the degree of fever.
four, commissioning the more convenient
we through improving the structure, electrical cam cam integration into four pieces of two piece, and isolation, top use t-screws spring against pine nuts pressure, improve the other factory using m3 screw position is not real, not, slippery silk, the m3 wrench not seek such shortcomings, and able to be in high and low temperatures, and always maintain the stability of the limit. (figure 3)
five, diaojiexing more stable and reliable
1. increased the size of the module, components selection wider, higher power;
2. the control of the power supply, electricity won't because of the voltage is not stable and affect module quality;
3. the bare plate heat is better;
4. a fool, a key type positioning, avoid too many buttons, debug user for disorder;
5. using intelligent module hanging installation, solve the actuator highest temperature 120 ℃, and the module of electronic components using temperature only 65 ℃ of conflict.
six, novel appearance, the more grade
avoid the appearance of waking, and unique selling point.
seven, manual wrench in the cabinet, the scene is not easy to throw (figure 4)
eight, and more convenient and reliable valve assembly (figure 5)
and pneumatic join way consistent, more benefit at standard unification, can effectively reduce the valve inventory.
and the stem is plugged directly into actuators internal worm gear place, allows the valve and the output shaft arm shorter, more stable output
we insist on each machine actuators used import of origin micro switch (omron), nsk bearings (), we adopt cnc processing center of boxes of production, all parts are made by the numerical control machine tool, so as to ensure machining precision assembling accuracy, the great degree, and reduce the friction transmission efficiency, increase that we can launch fast switch type: 2.8 seconds, 300 cattle meters, this product for the current domestic output torque is the smallest, the biggest and fastest electric actuators.
the expectations of customers is our efforts of the source, science is rigorous, technology is serious, quality is objective existence, we believe that with your eyes, with your professional knowledge to the analysis judgment, not listen to some manufacturer boasting, can certainly come to the correct conclusion. look forward to an opportunity for your company to provide our service!
